Boltz-2 NIM is a next-generation structural biology foundation model that shows strong performance for both structure and affinity prediction. Boltz-2 is the first deep learning model to approach the accuracy of free energy perturbation (FEP) methods in predicting binding affinities of small molecules and proteins—achieving strong correlations on benchmarks while being nearly 1000x more computationally efficient.
Trunk optimizations: Mixed-precision (bfloat16) and trifast triangle attention cut runtime/memory; enables training with 768-token crops (as in AlphaFold3).
Physical quality: Integrates Boltz-steering at inference (Boltz-2x) to reduce steric clashes and stereochemistry errors without losing accuracy.
Controllability:
Affinity module: PairFormer refines protein–ligand and intra-ligand interactions; predicts both binding likelihood and a continuous affinity on log µM scale (trained on mixed Ki, Kd, IC50). Output is an IC50-like measure suitable for ranking.
Key advances vs Boltz-1/1x: Faster/more memory-efficient trunk, improved physical plausibility via integrated steering, markedly enhanced controllability, and added affinity prediction head.
This NIM is ready for commercial use.
This model is not owned or developed by NVIDIA. This model has been developed and built to a third-party’s requirements for this application and use case.
GOVERNING HOSTING TERMS: Use of this trial service is governed by the NVIDIA API Trial Service Terms of Use. Use of this model is governed by the NVIDIA Open Model Agreement. ADDITIONAL INFORMATION: Apache License, Version 2.0 and MIT License.
You are responsible for ensuring that your use of NVIDIA provided models complies with all applicable laws.
Global
Boltz-2 NIM enables researchers and commercial entities in the Drug Discovery, Life Sciences, and Digital Biology fields to predict the three-dimensional structure of biomolecular complexes and predict small-molecule binding affinities. Trained on millions of curated experimental datapoints with a novel training strategy tailored for noisy biochemical assay data, Boltz-2 demonstrates robust performance across hit-discovery, hit-to-lead, and lead optimization.
build.nvidia.com: 6/16/2026 via build.nvidia.com/mit/boltz2
NGC: 6/16/2026 via catalog.ngc.nvidia.com
@article{passaro2025boltz2,
author = {Passaro, Saro and Corso, Gabriele and Wohlwend, Jeremy and Reveiz, Mateo and Thaler, Stephan and Somnath, Vignesh Ram and Getz, Noah and Portnoi, Tally and Roy, Julien and Stark, Hannes and Kwabi-Addo, David and Beaini, Dominique and Jaakkola, Tommi and Barzilay, Regina},
title = {Boltz-2: Towards Accurate and Efficient Binding Affinity Prediction},
year = {2025},
doi = {10.1101/2025.06.14.659707},
journal = {bioRxiv},
language = "en"
}
Architecture Type: Four components — trunk, denoising module (with steering), confidence module, and a new affinity module
Network Architecture: PairFormer
Input Type(s): Biomolecular sequences (protein, DNA, RNA), ligand SMILES or CCD strings, molecular modifications, structural constraints, conditioning parameters, optional booleans
Input Format(s): Dictionary containing sequence strings, modification records, and constraint parameters
Input Parameters: Sequences (strings), predict_affinity(boolean), modifications (list of residue-specific changes), constraints (dictionary of structural parameters)
Other Properties Related to Input: Maximum sequence length of 4096 residues per chain. Maximum of 12 input polymers. Maximum of 20 input ligands. Passing boolean options such as predict_affinity will increase the runtime of the request.
Model Parameters:
Tables 1 and 2 record some of the hyperparameters of Boltz-2's architecture, training and inference procedures that differ from Boltz-1's and were not previously mentioned in the manuscript.
Table 1: Extra model architecture and training hyperparameters that differ from Boltz-1 and were not previously mentioned in the manuscript.
| Parameter | Value |
|---|---|
| Max number of MSA sequences during training | 8192 |
| Template pairwise dim | 64 |
| Num template blocks | 2 |
| Training diffusion multiplicity | 32 |
| bfactor loss weight | 1 × 10⁻³ |
Table 2: Diffusion process hyperparameters that differ from Boltz-1, with the exception of sigma_min we opted for AlphaFold3's default hyperparameters, see Abramson et al. (2024) for more details.
| Parameter | Value |
|---|---|
| sigma_min | 0.0001 |
| rho | 7 |
| gamma_0 | 0.8 |
| gamma_min | 1.0 |
| noise_scale | 1.003 |
| step_scale | 1.5 |
Output Type(s): Structure prediction in mmcif format; scores in numeric arrays; runtime metrics as a dictionary
Output Format: mmcif (text file); numeric arrays; scalar numeric values
Output Parameters: 3D atomic coordinates, predicted scores, and metadata
Other Properties Related to Output: All Boltz-2 scores are returned by default. Runtime metrics are optional.
Our AI models are designed and/or optimized to run on NVIDIA GPU-accelerated systems. By leveraging NVIDIA's hardware (e.g. GPU cores) and software frameworks (e.g., CUDA libraries), the model achieves faster training and inference times compared to CPU-only solutions.
Runtime Engine(s):
Supported Hardware Microarchitecture Compatibility:
[Preferred/Supported] Operating System(s):
Boltz2 v2.2.1
** Data Modality
Link: Protein Data Bank as used by AlphaFold3
** Data Collection Method by dataset
** Labeling Method by dataset
Properties: All Protein Data Bank structures before 2021-09-30 with a resolution of at least 9 Angstroms, preprocessed to match each structure to its sequence. Ligands were processed similarly. All data was cleaned as described in AlphaFold3.
Link: Boltz Evaluation Performed on 744 Structures from the Protein Data Bank
** Data Collection Method by dataset
** Labeling Method by dataset
Properties:
The test and validation datasets were generated by extensive filtering of PDB sequences deposited between 2021-09-31 and 2023-01-13. In total, 593 structures passed filters and were used for validation.
Acceleration Engine: PyTorch, TensorRT
Test Hardware:
NVIDIA believes Trustworthy AI is a shared responsibility and we have established policies and practices to enable development for a wide array of AI applications. When downloaded or used in accordance with our terms of service, developers should work with their supporting model team to ensure this model meets requirements for the relevant industry and use case and addresses unforeseen product misuse. Please report model quality, risk, security vulnerabilities or NVIDIA AI Concerns here.
You are responsible for ensuring the physical properties of model-generated molecules are appropriately evaluated, and comply with applicable safety regulations and ethical standards.
