# Pretrained Grounding DINO with Commercial License ## Description Open vocabulary object detection is a computer vision technique that can detect one or multiple objects in a frame based on the text input. Object detection recognizes the individual objects in an image and places bounding boxes around the object. This model card contains pre-trained weights for the [Grounding DINO](https://arxiv.org/abs/2303.05499) object detection networks pretrained on the commercial dataset. Note that the model in this model card can be used for commercial purpose. ## References - Zhang, H., Li, F., Liu, S., Zhang, L., Su, H., Zhu, J., Ni, L., Shum, H.: DINO: DETR with Improved DeNoising Anchor Boxes for End-to-End Object Detection. - Ziu, S., Zeng, Z., Ren, T., Li, F., Zhang, H., Yang, J., Li, C., Yang, J., Su, H., Zhu, J., Zhang, L.: Grounding DINO: Marrying DINO with Grounded Pre-Training for Open-Set Object Detection. - Devlin, J., Chang, M., Lee, K., Toutanova, K.: BERT: PRe-training of Deep Bidirectional Transformers for Language Understanding. - Liu, Z., Lin, Y., Cao, Y., Hu, H., Wei, Y., Zhang, Z., Lin, S., Guo, B.: Swin Transformer: Hierarchical Vision Transformer using Shifted Windows. ## License The licenses to use this model is covered by the Model EULA. By downloading the unpruned or pruned version of the model, you accept the terms and conditions of these [licenses](https://www.nvidia.com/en-us/data-center/products/nvidia-ai-enterprise/eula/) ## Model Architecture **Architecture Type:** Transformer-based Network Architecture **Network Architecture** - Backbone: Window attention based Transformers called Swin-Tiny and BERT-Base text encoder. - Encoder: 6 layers of Multi-headed attention with deformable attention layers. - Decoders: 6 layers of Multi-headed attention with deformable attention layers. **More Details** - The models in this instance are object detectors that take RGB images and list of phrases as input and produce bounding boxes and classes as output. More specifically, this model was trained with [Swin-Tiny backbone](https://arxiv.org/pdf/2103.14030) that was trained using a supervised manner on NVIDIA proprietary data called NVImageNetv2, which allows commercial usage. In addition, BERT-Base was used as the starting weight for text tower. Finally, Grounding DINO was trained end-to-end on about 1.8M images that were collected from publicly available datasets. Note that we ensured that all the raw images used during training have commercial licenses to ensure safe commercial usage. ### Input **Input Type(s):** Image and list of captions of tokenized through HuggingFace
**Input Format(s):** Red, Green, Blue (RGB) and tokenized inputs. Can support any input resolution and images do not need any additional pre-processing (e.g. alpha channels or bits)
**Input Parameters:** Multiple dimensions. See below for detailed input shapes
**Other Properties Related to Input:**
- `inputs`: B X 3 X 544 X 960 (Batch Size x Channel x Height x Width) - `input_ids`: B x 256 (Batch Size x Max Token Length ) - `attention_mask`: B x 256 (Batch Size x Max Token Length ) - `position_ids`: B x 256 (Batch Size x Max Token Length ) - `token_type_ids`: B x 256 (Batch Size x Max Token Length ) - `text_token_mask`: B x 256 x 256 (Batch Size x Max Token Length x Max Token Length) - Because ONNX / TensorRT can't take string as input, we've offloaded tokenizer outside of the model graph. See [TAO-Deploy](https://github.com/NVIDIA/tao_deploy) repo on running tokenization through HuggingFace. building change

### Output **Output Type(s):** Bounding Boxes and Confidence Scores for each detected object in the input image.
**Output Formats:** One Dimensional (1D), Two Dimensional (2D) vectors
**Other Properties Related to Output:**
- `pred_logits`: B x 900 (Batch Size x Number of Queries) - `pred_boxes`: B x 900 x 4 (Batch Size x Number of Queries x Coordinates in `cxcywh` format) ## Software Integration **Runtime Engine(s):** * TAO - 5.5.0
**Supported Hardware Architecture(s):**
* NVIDIA Ampere
* NVIDIA Jetson
* NVIDIA Hopper
* NVIDIA Lovelace
* NVIDIA Pascal
* NVIDIA Turing
* NVIDIA Volta
**Supported Operating System(s):**
* Linux
* Linux 4 Tegra
## Model Versions - **grounding_dino_swin_tiny_commercial_trainable_v1.0** - Pre-trained Swin-Tiny Grounding DINO model for finetune. - **grounding_dino_swin_tiny_commercial_deployable_v1.0** - Swin-Tiny Grounding DINO model deployable. ## Training & Evaluation: This model was trained using the `grounding_dino` entrypoint in TAO. The training algorithm optimizes the network to minimize the localization and contrastive embedding loss between text and visual features. ## Using this Model These models need to be used with NVIDIA hardware and software. For hardware, the models can run on any NVIDIA GPU including NVIDIA Jetson devices. These models can only be used with [Train Adapt Optimize (TAO) Toolkit](https://developer.nvidia.com/tao-toolkit), or [TensorRT](https://developer.nvidia.com/tensorrt). The intended use for these models is detecting objects in a color (RGB) image. The model can be used to detect objects from photos and videos by using appropriate video or image decoding and pre-processing. These models are intended for training and fine-tune with the TAO Toolkit and your datasets for object detection. High-fidelity models can be trained with new use cases. A Jupyter Notebook is available as a part of the pytorch [TAO container](https://catalog.ngc.nvidia.com/orgs/nvidia/teams/tao/containers/tao-toolkit/tags) and can be used to re-train. The models are also intended for easy edge deployment using TensorRT. ## Training Dataset ### Training Data Grounding DINO was pretrained on wide range of commercial datasets where the annotations were either human generated or pseudo-labeled. The model was trained on 1,815,237 images and 14,794,974 instances of both object detection (OD) and grounding annotations. Please refer to below section for details of every dataset used to train Grounding DINO. | Dataset | Data Collection Method by dataset | Labeling Method by dataset | # of Images|# of Annotations| |--------------------------------|-----------------------------------|----------------------------|------------|----------------| | Subset of OpenImagesv5 | Unknown | Automated. Pseudo-labeled raw images with Objects365 trained CO-DETR. |803,826 | 7,345,546| | Localized Narrative OpenImages | Unknown | Automated. Pseudo-labeled raw images and global captions with Grounding DINO. | 670,553 | 6,098,908| | Subset of LVIS | Unknown | Human-labeled (only contains commercial subset). | 30,740 | 391,840 | | Subset of Mixed Grounding | Unknown | Human-labeled (only contains commercial subset). | 150,668 | 777,178 | | Subset of RefCOCO | Unknown | Human-labeled (only contains commercial subset). | 36,459 | 36,459 | | Subset of RefCOCO+ | Unknown | Human-labeled (only contains commercial subset). | 36,302 | 36,302 | | Subset of RefCOCOg | Unknown | Human-labeled (only contains commercial subset). | 23,718 | 23,718 | | Subset of gRefCOCO | Unknown | Human-labeled (only contains commercial subset). | 62,971 | 85,023 | ## Evaluation Data **Data Collection Method by dataset:**
- Unknown
**Labeling Method by dataset:**
- Human.
**Properties:**
- COCO validation dataset with 5,000 images. ### Methodology and KPI The key performance indicator is the mean average precision (mAP), following the standard evaluation protocol for object detection. The KPI for the evaluation data are: |model|precision|mAP|mAP50|mAP75|mAPs|mAPm|mAPl| |---|---|---|---|---|---|---|---| |grounding_dino_swin_tiny|BF16|46.1|59.9|51.0|30.5|49.3|60.8| ## Model Limitation Grounding DINO was trained on images collected from the web and text data of everyday noun phrases. The model might not perform well on different data distributions. Conducting further fine-tuning on the target domain is recommended to get a higher mAP. ## Technical Blogs - [Train like a ‘pro’ without being an AI expert using TAO AutoML](https://developer.nvidia.com/blog/training-like-an-ai-pro-using-tao-automl/) - [Create Custom AI models using NVIDIA TAO Toolkit with Azure Machine Learning ](https://developer.nvidia.com/blog/creating-custom-ai-models-using-nvidia-tao-toolkit-with-azure-machine-learning/) - [Developing and Deploying AI-powered Robots with NVIDIA Isaac Sim and NVIDIA TAO](https://developer.nvidia.com/blog/developing-and-deploying-ai-powered-robots-with-nvidia-isaac-sim-and-nvidia-tao/) - Learn endless ways to adapt and supercharge your AI workflows with TAO - [Whitepaper](https://developer.nvidia.com/tao-toolkit-usecases-whitepaper/1-introduction) - [Customize Action Recognition with TAO and deploy with DeepStream](https://developer.nvidia.com/blog/developing-and-deploying-your-custom-action-recognition-application-without-any-ai-expertise-using-tao-and-deepstream/) - Read the two-part blog on training and optimizing 2D body pose estimation model with TAO - [Part 1](https://developer.nvidia.com/blog/training-optimizing-2d-pose-estimation-model-with-tao-toolkit-part-1) | [Part 2](https://developer.nvidia.com/blog/training-optimizing-2d-pose-estimation-model-with-tao-toolkit-part-2) - Learn how to train a [real-time License plate detection and recognition app](https://developer.nvidia.com/blog/creating-a-real-time-license-plate-detection-and-recognition-app) with TAO and DeepStream. - Model accuracy is extremely important; learn how you can achieve [state of the art accuracy for classification and object detection models](https://developer.nvidia.com/blog/preparing-state-of-the-art-models-for-classification-and-object-detection-with-tao-toolkit/) using TAO. ## Suggested Reading - More information on TAO Toolkit and pre-trained models can be found at the [NVIDIA Developer Zone](https://developer.nvidia.com/tao-toolkit) - Refer to the [TAO documentation](https://docs.nvidia.com/tao/tao-toolkit/index.html) - Read the [TAO Toolkit Quick Start Guide](https://docs.nvidia.com/tao/tao-toolkit/index.html) and [release notes](https://docs.nvidia.com/tao/tao-toolkit/text/release_notes.html). - If you have any questions or feedback, please refer to the discussions on the [TAO Toolkit Developer Forums](https://forums.developer.nvidia.com/c/accelerated-computing/intelligent-video-analytics/tao-toolkit/17) - Deploy your models for video analytics application using the [DeepStream SDK](https://developer.nvidia.com/deepstream-sdk). - Deploy your models in [Riva](https://developer.nvidia.com/riva) for ConvAI use case. ## Ethical Considerations NVIDIA believes Trustworthy AI is a shared responsibility and we have established policies and practices to enable development for a wide array of AI applications. When downloaded or used in accordance with our terms of service, developers should work with their supporting model team to ensure this model meets requirements for the relevant industry and use case and addresses unforeseen product misuse. For more detailed information on ethical considerations for this model, please see the Model Card++ Promise and the Explainability, Bias, Safety & Security, and Privacy Subcards. Please report security vulnerabilities or NVIDIA AI Concerns [here](https://www.nvidia.com/en-us/support/submit-security-vulnerability/).
